AutoJet® HP170 Lubrication System

Automated Lubrication Systems

AutoJet® HP170 Lubrication System

The newly developed AutoJet® HP170 Lubrication System is specifically designed for applications where lines with speed variations require a constant amount of heated lubricant per m².

The AutoJet® systems operate at line speeds up to 300 m/min delivering a pre-set amount of lubricant evenly across the coil regardless of machine speed. Our PWM controllers and PulsaJet® spray nozzles adjust flow to match speed variations during the run: the result is consistency from start to finish. From slow speeds to fast speeds and back again the amount you pre-set will be the amount you get.

Easy and accurate set up

The system is easy to set up and operate. Enter the amount of lubricant you require, select the number of nozzles based on coil width and press start! The AutoJet® controller signals our PulsaJet® spray nozzles to ensure the application rate is always perfect. Fully hydraulic sprays are used for most applications, but for extremely viscous oils, we also have an air-assisted nozzle.

Temperature control allows the use of whichever lubricant you prefer

The HP170 system can handle most high viscosity oils (wax-based, anti-corrosion, …). These types of oil are more thixotropic which enables them to remain on the coil in all conditions. However, the oils must be applied at elevated temperatures, sometimes above 55 °C.

The HP170 has temperature control built into the system, allowing the operator to select the correct temperature for the oil in your process.


Dimensions and weights

Ideal for use in these applications

  • Corrosion protection
  • Roll forming
  • Stamping
  • Wire lubrication
  • Tube lubrication
Contact us about using AutoJet® Systems for you application. Talk to an expert
