AutoJet® Systems for food applications

AutoJet® BAV-20 AccuGlaze®

AutoJet® Systems for food applications

The AutoJet® BAV-20 AccuGlaze® is an autonomous glazing system with pressure tank and conveyor for bakeries.

Brochure: AutoJet® AccuGlaze BAV-20

Pressure tank 20 liter
Control panel:
- F1850+ food controller
- Speed control for conveyor
- Triggered by inductive sensor
- Low level switch
PWM Modes: Fixed duty cycle
Mobile hygienic frame
Spray nozzle header with height adjustment
Small footprint
Available for plate width: 400mm or 600mm
Hygienic design: easy wash-down
Two folding plates for snap-in
Configuration for plates (2 small belts) and objects (large belt)
Conveyor belt without tension = safe operation
Nozzles:
- 400mm: 2 to 6 PulsaJet^® Nozzles
- 600mm: 2 to 8 PulsaJet^® Nozzles
Consumables:
- Compressed air (6 bar)
- Electricity (230 VAC)

Ideal for these applications:

Find the AutoJet® Food System that's right for your application Talk to an expert
