Spray Nozzles

Spray nozzles are used to apply liquid to any application or product that requires it. Nozzles are available in all shapes, sizes and materials. The different designs result in spray characteristics that offer a wide variety of  droplet sizes, flow rates, pressure rates, spray angles and spray patterns. Selecting the nozzle with the right spray characteristics will determine the performance of your spray application.

Spray Nozzles 101

As the type and shape of the spray from a nozzle can determine the effectiveness and efficiency of your spray operations. We've listed the basics here.

Spray patterns

• Full Cone: Full cone spray nozzles produce medium- to large-size drops forming a solid cone-shaped spray pattern with a round impact area.
  The unique vane design features large flow passages to provide superior control and uniform distribution. The full cone spray pattern is ideal for washing, rinsing, cooling, dust control and fire protection.
• Flat Spray: Flat spray nozzles produce small- to medium-sized drops forming a flat or sheet-type spray pattern that's typically used in manifolds and headers.

  The flat spray pattern is ideal for cleaning, rinsing, pressure washing, cooling, coating and surface preparation.
• Hollow Cone: Hollow cone nozzles produce small- to medium-sized drops forming a hollow cone pattern with a ring-shaped impact area. The large, unobstructed flow passage minimizes clogging, allowing for uniform distribution at a wide range of flow rates and pressures, and effective atomization of liquids at lower pressures. The hollow cone spray pattern is ideal for cooling, washing, gas scrubbing / cooling, dust control and fire protection.
• Fine Spray: Fine spray nozzles produce very small drops using liquid pressure only - no compressed air required. These nozzles ensure uniform distribution at a wide range of flow rates and pressures, and are easy to maintain. Fine spray nozzles are ideal for humidifying, fogging, gas cooling, evaporative cooling, dust control, moistening, and fire protection.
• Air Atomizing: Air atomizing spray nozzles (also called two-fluid nozzles) produce finely atomized sprays using compressed air.

Our range consists of 90,000+ spray nozzles to ensure a perfect fit for your spray process. You can browse through our range by selecting the spray nozzle product group below or by contacting your local spray expert.
